Flexible Metal Conduit, Square-lock Galvanized Steel
Flexible Metal Conduit, PAG13X series is manufactured with galvanized steel strip by continuous wound in square-lock profile. This series of flexible metal conduit is developed with 3 classified levels, Light, Medium & Heavy, for different applications. The conduit sizes meet with the system normally used in Asia market. This series of product is good in flexibility and suitable for most of the environment temperatures. It is also Low Fire Hazard. The electrical and mechanical performances are approved with IEC 61386 standard. The material is RoHS approved as well. Applicable for electrical protection in Buildings, Railway System, Marines, Elevators, and etc..
Feature
-
Material:
Galvanized Steel -
Profile：
Square-lock -
Temperature Range :
-45℃~+350℃ -
IP Rating :
IP 40
-
Flexibility :
High (≤ 2") -
Tensile Resistance :
500N -
RoHS Compliance :
Yes -
Certificate :
CE
Parameter
| Nominal Conduit Size | Nominal Conduit Size | Part Number | ID (mm) | OD (mm) | Bending Radius (mm) | Package/Roll (m) | Measurement (LxWxH mm) | Certificate | Mated With |
|---|---|---|---|---|---|---|---|---|---|
| 10 | 1/4 | PAG13X-10 | 8.0 | 10.7 | 25 | 50 | 300*300*100 |
| - |
| 12 | 5/16 | PAG13X-12 | 10.3 | 13.0 | 30 | 50 | 300*300*200 |
|
|
| 16 | 3/8 | PAG13X-16 | 12.6 | 15.6 | 35 | 50 | 330*330*200 |
|
|
| 20 | 1/2 | PAG13X-20 | 16.1 | 19.7 | 35 | 50 | 380*380*210 |
|
|
| 25 | 3/4 | PAG13X-25 | 21.1 | 24.7 | 45 | 50 | 450*450*220 |
|
|
| 32 | 1 | PAG13X-32 | 26.8 | 30.7 | 50 | 25 | 450*450*200 |
|
|
| 40 | 1-1/4 | PAG13X-40 | 35.4 | 40.2 | 65 | 25 | 500*500*250 |
|
|
| 50 | 1-1/2 | PAG13X-50 | 40.3 | 44.9 | 85 | 25 | 550*550*200 |
|
|
| 63 | 2 | PAG13X-63 | 51.6 | 56.6 | 90 | 15 | 550*550*500 |
|
|
| 75 | 2-1/2 | PAG13X-75 | 63.3 | 70.3 | 145 | 10 | 550*550*450 |
|
|
| 90 | 3 | PAG13X-90 | 78.0 | 85.6 | 170 | 10 | 1000*1000*200 |
|
|
| 110 | 4 | PAG13X-110 | 102.5 | 110.1 | 210 | 10 | 1000*1000*400 |
|
|
Frequently Asked Questions: Square-lock Galvanized Steel Conduit
Q1: What are the main advantages of the Square-lock structure?
The Square-lock design provides excellent flexibility and high mechanical strength. It allows the conduit to be easily bent while maintaining its shape, making it ideal for protecting cables in tight spaces or environments with constant vibration.
Q2: What does "LFH (Low Fire Hazard)" mean for this conduit?
LFH indicates that the conduit is designed for safety-critical environments. In the event of a fire, it limits the spread of flames and generates minimal smoke and toxic fumes, which is essential for public buildings, tunnels, and subway systems.
Q3: Is the galvanized steel finish corrosion-resistant?
Yes. The high-quality hot-dipped galvanized steel construction provides a strong protective layer against rust and corrosion, ensuring a long service life in dry and indoor industrial environments.
Q4: What temperature range can this flexible metal conduit withstand?
As it is made of pure galvanized steel without a plastic jacket, it can withstand significantly higher temperatures than PVC-coated versions, typically ranging from -50°C to +300°C, depending on the specific application.
Q5: Can Kaiflex provide matching fittings for this conduit?
Absolutely. As a professional manufacturer, we provide a complete range of brass and zinc alloy fittings specifically designed to match our Square-lock conduits, ensuring a secure and easy installation.
