Quick Ass'y, Fixed Type Conduit Fitting
Metal Conduit Fittings AZ01 series is a three-piece straight connector and has been designed to meet with IEC 60423 standard. The AZ01 series is applied on the relay or end point of wiring system to connect metal conduits and junction box or enclosure for wiring extension and protection. The body is made of zinc alloy with RoHS compliance which is connected with metal flexible conduit by screwing in and covering with a nut and fixed to the knockouts of junction box or tapped entries by locknut with optional male thread system, M type, G type or PG type. The concise structure design is benefit for quick and convenient assembly but remain the feature of high tensile resistance at the mean time. Adding an extra grounding ring for grounding purpose. This series of fitting is proposed to fit with flexible metal conduit series PAG13 and PAS13 with or without plastic jacket.
Feature
-
Material:
Zinc Alloy -
Temperature Range:
-50℃~+200℃ -
IP Rating:
IP 40 -
Surface Finish :
Zinc plated, other treatments are available by consult. -
RoHS Compliance :
Yes -
Certificate :
CE
Parameter
G Thread
| Nominal Conduit Size | Nominal Conduit Size | G Thread | Part Number | Package/Box (Pcs) | Weight/Box (Kg) | Certificate | Mated With |
|---|---|---|---|---|---|---|---|
| 12 | 5/16 | 1/2" | G1/2-AZ01-5/16 | 600 | 14.7 |
|
|
| 16 | 3/8 | 1/2" | G1/2-AZ01-3/8 | 600 | 16.6 |
|
|
| 20 | 1/2 | 1/2" | G1/2-AZ01-1/2 | 400 | 13.6 |
|
|
| 25 | 3/4 | 3/4" | G3/4-AZ01-3/4 | 340 | 19.9 |
|
|
| 32 | 1 | 1" | G1-AZ01-1 | 180 | 15.5 |
|
|
| 40 | 1-1/4 | 1-1/4" | G1-1/4-AZ01-1-1/4 | 100 | 13.6 |
|
|
| 50 | 1-1/2 | 1-1/2" | G1-1/2-AZ01-1-1/2 | 50 | 9 |
|
|
| 63 | 2 | 2" | G2-AZ01-2 | 40 | 9.4 |
|
|
| 75 (N/A) | 2-1/2 | 2-1/2" | G2-1/2-AZ01-2-1/2 |
|
| ||
| 90 (N/A) | 3 | 3" | G3-AZ01-3 |
|
| ||
| 110 (N/A) | 4 | 4" | G4-AZ01-4 |
|
|
PG Thread
| Nominal Conduit Size | Nominal Conduit Size | PG Thread | Part Number | Package/Box (Pcs) | Weight/Box (Kg) | Certificate | Mated With |
|---|---|---|---|---|---|---|---|
| 12 | 5/16 | PG9 | PG9-AZ01-12 | 900 | 14.5 |
|
|
| 16 | 3/8 | PG11 | PG11-AZ01-16 | 900 | 19 |
|
|
| 20 | 1/2 | PG16 | PG16-AZ01-20 | 600 | 17.8 |
|
|
| 25 | 3/4 | PG21 | PG21-AZ01-25 | 360 | 17.2 |
|
|
| 32 | 1 | PG29 | PG29-AZ01-32 | 180 | 13.6 |
|
|
| 40 | 1-1/4 | PG36 | PG36-AZ01-40 | 100 | 12.8 |
|
|
| 50 | 1-1/2 | PG42 | PG42-AZ01-50 | 50 | 8.5 |
|
|
| 63 | 2 | PG48 | PG48-AZ01-63 | 40 | 9 |
|
|
M Thread
| Nominal Conduit Size | Nominal Conduit Size | M Thread | Part Number | Package/Box (Pcs) | Weight/Box (Kg) | Certificate | Mated With |
|---|---|---|---|---|---|---|---|
| 12 | 5/16 | M16x1.5 | M16-AZ01-12 | 900 | 16.8 |
|
|
| 16 | 3/8 | M16x1.5 | M16-AZ01-16 | 900 | 19.9 |
|
|
| 20 | 1/2 | M20x1.5 | M20-AZ01-20 | 600 | 19 |
|
|
| 25 | 3/4 | M25x1.5 | M25-AZ01-25 | 360 | 19 |
|
|
| 32 | 1 | M32x1.5 | M32-AZ01-32 | 180 | 14.5 |
|
|
| 40 | 1-1/4 | M40x1.5 | M40-AZ01-40 | 100 | 13.2 |
|
|
| 50 | 1-1/2 | M50x1.5 | M50-AZ01-50 | 50 | 8.7 |
|
|
| 63 | 2 | M63x1.5 | M63-AZ01-63 | 40 | 8.9 |
|
|
| 75 (N/A) | 2-1/2 | M75x1.5 | M75-AZ01-75 |
|
| ||
| 90 (N/A) | 3 | M90x2 | M90-AZ01-90 |
|
| ||
| 110 (N/A) | 4 | M110x2 | M110-AZ01-110 |
|
|
Technical FAQ: Fixed Type Conduit Fittings
Q1: What is a "Fixed Type" conduit fitting?
A Fixed Type fitting features a non-rotatable thread design. It provides a highly secure and rigid connection between the flexible metal conduit and the junction box or enclosure, ensuring maximum stability in static installations.
Q2: Why choose Fixed Fittings for LFH (Low Fire Hazard) applications?
In safety-critical environments like subways or tunnels, simplicity is key. Fixed fittings have fewer moving parts, reducing potential points of failure during extreme conditions while maintaining the integrity of the fire-safe cable protection system.
Q3: What thread standards do these fittings support?
Kaiflex offers a wide range of thread options to meet international standards, including NPT (North American), Metric (European/ISO), and PG threads. Custom thread sizes are also available upon request.
Q4: What materials are available for the Fixed Type fittings?
Our fittings are typically precision-machined from Nickel-Plated Brass or Zinc Alloy, providing excellent mechanical strength and corrosion resistance for long-term industrial use.
